CH4x4 Rocker Switch Air Compressor Symbol – Horizontal – Green LED
Last update was on: September 8, 2024 12:38 am
- Single Pole Single Throw ON-OFF switch.
- Two LEDs in the switch. Upper LED is ON only when the switch is turned ON. Lower LED is independent. Both LEDs have separate grounds.
- Black hard surface rocker. Same size as the Carling and ARB switches.
- Rated 16A 12V.
- Wiring diagram supplied with switch.
VIAIR 400C 150 PSI Dual Performance Value Pack – Chrome
Last update was on: September 8, 2024 12:38 am
- TWO Chrome 12 VOLT 400C Air Compressors - 150 PSI MAX Working pressure, engine must be running during use.
- 4.55 CFM Free Flow @ 0 PSI
- Comes with two heavy duty 40-amp relays and a 110 to 145 PSI Pressure switch, please consult website for wiring diagram.
- Built-in thermal overload protector serves to protect the compressor from overheating the in harshest operating environments.
- Can fill at 2.5 gallon tank from 0 to 145PSI in 1 minutes and 8 seconds. Can fill at 5.0 gallon air tank from 0 to 145PSI in 2 minutes and 20 seconds.
CH4X4 Push Switch for Toyota – Air Compressor Symbol 3 – Blue LED
Last update was on: September 8, 2024 12:38 am
- Single Pole Single Throw ON-OFF switch.
- Two LEDs in the switch. Upper LED is ON only when the switch is turned ON. Lower LED is independent. Both LEDs have separate grounds.
- Black hard surface rocker. Same size as the Carling and ARB switches.
- Rated 16A 12V.
- Wiring diagram supplied with switch.
